This product is designed for dimming with options for 1-10V, potentiometer, or 10V PWM and features a constant voltage design. It can accept universal AC input and has a full range. It is IP66 rated, making it suitable for both indoor and outdoor installations. It also offers various protections including short circuit, overload, over voltage, and over temperature. Additionally, it has a built-in PFC function with a rate of more than 0.98, cooling through free air convection, and an efficiency of over 83%.
|
Wattage |
45 |
|
Input Voltage (V) |
100-265Vac |
|
Output Current (A) |
1.87 |
|
Output Voltage (V) |
24 |
|
Output Voltage Options |
Single |
|
DC output adjustment |
N/A |
|
Working Temperature |
-40~+60°C |
|
Safety Standards |
EN61347-2-13, IP66 |
|
EMC Standards |
Compliance to EN55015, EN61000-3-2 (>50%load), Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547, A light industry level |
|
Dimensions (LxWxH) mm |
179x 60.4x 35.2mm |
